Product details
Product Description:|
Electrical
|
||
|
Standard
|
UL
|
IEC
|
|
Rated voltage
|
300V
|
450V
|
|
Rated current
|
20A
|
24A
|
|
Wire range
|
26-12AWG
|
0.5-2.5mm2
|
|
Withstanding voltage
|
AC2000V/1Min
|
|
|
|
||
|
Mechanical
|
||
|
Torque
|
0.5Nm(4.4Lb-In.)
|
|
|
Ambient temperature
|
-40°C~+105°C
|
|
|
Strip length
|
7mm
|
|
|
|
||
|
Dimensions
|
||
|
Pitch
|
5.0 mm (.197")
|
|
|
Poles
|
2P,3P-24P
|
|
|
|
||
|
Material
|
||
|
Housing
|
PA66,UL94V-0
|
|
|
Screws
|
M3,steel,Cr3+ Zn plated
|
|
|
Pin header
|
Brass,Tin plated
|
|
|
Cage
|
Brass,Ni plated
|
|
